JBC1530 CNC ROUTER
JBC CNC machining center is suitable for all kinds of complex products or various machining. It can realize the cutting, engraving, drilling, wiring and grooving of wood, medium density board, acrylic, PVC, plastic, foam, stone, soft metal and other materials.
It can be equipped with different tool library and quantity according to different production process, and other options can also be added, such as spindle swing, side rotating shaft, etc.
|
Technical Indicators
|
Parameter
|
|---|---|
|
Model
|
JBC-1530
|
|
Working area (X,Y,Z)
|
1500*3000*400mm
|
|
Max. empty speed
|
50000mm/min
|
|
Max. working speed
|
30000mm/min
|
|
Spindle Power
|
HQD 9.0kw air cooled tool change spindle
|
|
Positional accuracy
|
0.03mm
|
|
X,Y axis drive
|
Rack
|
|
Z axis drive
|
Ball screw
|
|
Repeated positioning accuracy
|
0.02mm
|
|
Command language
|
G Code
|
|
Port
|
USB
|
|
Working voltage
|
AC220V/380V
|
- Body
- Heavy-duty welded frame
- Gantry
- Steel Structure
- Spindle
- HQD 9.0kw air-cooled JBC spindle
- Table
- Vacuum adsorption table with T-slot
- Guide rail
- TAIWAN HIWIN
- Rack
- TANWAN XINYUE
- Screw
- TAIWAN TBI
- Drive
- Servo 1.5kw
- Reducer
- Japan SHIMPO
- Inverter
- Fuling
- Electrical element
- SCHNEIDER
- Tricolor light
- Yes
- Tool changer
- Straight line tool change, 8 tool positions
- Tool setting gauge
- Automatic tool setting gauge
- Locks the tool apron
- Yes
- Lubrication system
- Automatic oil filling
- Intelligent control system
- TAIWAN LNC
- Dust collector
- 3KW with two bags
- Vacuum pump
- 7.5kw air.wter-cooled vacuum pump
HQD 9KW air-cooled spindle
High rotary precision, small vibration, durable, long life.
Vacuum adsorption table, strong adsorption force, each area can be controlled separately; In addition to T slot, for different materials processing more convenient.
The number of knife storage can be increased according to different processes.
Jaba Center independent cabinet, upgraded to 21 inch touch screen, humanized design, Taiwan new generation system, use mouse and keyboard to operate, easy and convenient.
Metal material, durable, flexible and convenient, effective protection of the handle, easy to disassemble the tool.
Add a storage box to keep your tools handy and keep your countertops clean and tidy.
Using Taiwan HIWIN guide rail and XINYUE rack, high positioning accuracy, smooth sliding, reliable quality, long life.
With rich internal position, internal speed and internal torque control functions, superior performance, reliable quality.
Mute; High rigidity, high torque, precise positioning; Small wear, long service life.
More optimized function, more flexible application, more stable performance, higher performance and accuracy.
Samples
Wooden furniture industry: solid wood and composite door, cupboard door, sliding door, paint door, flexible packaging, plate carving, wood carving, machining, antique mahogany furniture, solid wood panel furniture murals carved, etc.;
Wooden crafts industry: clock frame, picture frame, calligraphy CARDS, electrical appliances, sports equipment, thin aluminum plate engraving mesa sculpture;
Advertising industry: acrylic, PVC, MDF, artificial stone, organic glass, plastic, copper, aluminum and other soft sheet metal.
